The Bandit G4R takes motor efficiency to the next level with cutting-edge thermal management technology. In the same input power, the Bandit G4R is about 15°C cooler than the G4 motor.
Using high thermal conductivity glue to fill gaps in the stator coil, it ensures optimal heat dissipation and enhances overall reliability.
Adjustable timing for maximum power
The Bandit G4R motor features an adjustable mechanical timing angle ranging from 20 to 60 degrees, providing unmatched versatility and performance.
Efficient heat dissipation
The Bandit G4R motor features a fully exposed stator core outer diameter structure, setting a new benchmark for thermal efficiency. By directly exposing the stator core to air, the design optimizes the outer diameter and maximizes the heat dissipation area.
13.5T dual version options
The Bandit G4R 13.5T motor is available in two specialized versions Torque and OBL. Designed to meet diverse competitive needs with precision and power. The Torque version comes standard with super strong rotors, which is suitable for Blinky application. The OBL version is lighter, shorter, and provides more RPM. It’s suitable for OBL Stock Class that delivering exceptional speed applications.
Dual Hall sensing port design
The Bandit G4R motor incorporates a dual hall output socket design at the rear, revolutionizing the way wiring is managed for both functionality and aesthetics.
Designed for Easy disassembly and maintenance
The Bandit G4R features a modular structure design, making daily cleaning and maintenance straightforward while enhancing motor durability and efficiency.
The outlet end adopts a customized widened U-shaped gold-plated curved copper bar. It has extremely low internal resistance, it also increases the space between the copper bars for ease of soldering.
The large opening heat dissipation structure at the rear of the motor enhances the heat dissipation effect of the Hall component.
Specification:
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 2
Relevant Parameters:
KV Rating: 3200KV
LiPo Cells: 1-3S
No-load Current(A): 5.3A
Size & Weight:
O.D.(mm): 35.8
Length (mm): 53.9
Shaft Diameter (mm): 3.175
Weight (g): 190g
Front Bearing: D9*D4*T4
Rear Bearing: D8*D3*T4
Other Parameters:
Recommended ESC: XERUN XR10 PRO G3
Vehicle Applications: 1/10th Outlaw Stock Racing
Package total weight: 247.00 grams (incl. packaging)
Package size: 9.00 x 12.50 x 7.00cm
Factory description: Hobbywing 1/10 Sensored Brushless Motor XERUN BANDIT-13.5T-BLACK-G4R-TORQUE
The Bandit G4R takes motor efficiency to the next level with cutting-edge thermal management technology. In the same input power, the Bandit G4R is about 15°C cooler than the G4 motor.
Using high thermal conductivity glue to fill gaps in the stator coil, it ensures optimal heat dissipation and enhances overall reliability.
Adjustable timing for maximum power
The Bandit G4R motor features an adjustable mechanical timing angle ranging from 20 to 60 degrees, providing unmatched versatility and performance.
Efficient heat dissipation
The Bandit G4R motor features a fully exposed stator core outer diameter structure, setting a new benchmark for thermal efficiency. By directly exposing the stator core to air, the design optimizes the outer diameter and maximizes the heat dissipation area.
13.5T dual version options
The Bandit G4R 13.5T motor is available in two specialized versions Torque and OBL. Designed to meet diverse competitive needs with precision and power. The Torque version comes standard with super strong rotors, which is suitable for Blinky application. The OBL version is lighter, shorter, and provides more RPM. It’s suitable for OBL Stock Class that delivering exceptional speed applications.
Dual Hall sensing port design
The Bandit G4R motor incorporates a dual hall output socket design at the rear, revolutionizing the way wiring is managed for both functionality and aesthetics.
Designed for Easy disassembly and maintenance
The Bandit G4R features a modular structure design, making daily cleaning and maintenance straightforward while enhancing motor durability and efficiency.
The outlet end adopts a customized widened U-shaped gold-plated curved copper bar. It has extremely low internal resistance, it also increases the space between the copper bars for ease of soldering.
The large opening heat dissipation structure at the rear of the motor enhances the heat dissipation effect of the Hall component.
Specification:
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 2
Relevant Parameters:
KV Rating: 3200KV
LiPo Cells: 1-3S
No-load Current(A): 5.3A
Size & Weight:
O.D.(mm): 35.8
Length (mm): 53.9
Shaft Diameter (mm): 3.175
Weight (g): 190g
Front Bearing: D9*D4*T4
Rear Bearing: D8*D3*T4
Other Parameters:
Recommended ESC: XERUN XR10 PRO G3
Vehicle Applications: 1/10th Outlaw Stock Racing
Product weight: 247.00 grams
Package size: 9.00 x 12.50 x 7.00cm
Factory description: Hobbywing 1/10 Sensored Brushless Motor XERUN BANDIT-13.5T-BLACK-G4R-TORQUE
