220°C temperature-resistant insulated copper wire. 0.2mm silicon steel sheet reduces eddy current loss, enhancing magnetic flux density
Imported precision bearings and premium magnetic circuit system.
Triple core components ensure stable output under extreme conditions.
Smooth Operation & Exceptional Performance
The rotor has been calibrated with high-precision dynamic balancing, which reduces vibration, improves energy efficiency, and provides smooth low-speed control.
Small size, high torque: Powerful at low speeds and even stronger at high speeds.
ESC Features:
Designed for all-weather conditions with waterproof and dustproof protection, delivering outstanding start-up, acceleration, and linear response.
Compatible with sensorless brushless and brushed motors. Provides ultra-low-speed linear control, enabling smooth and stable start-up from as low as 0.1 km/h.
Equipped with sensorless FOC for high torque and low-speed performance, featuring a high magnetic flux MOSFET drive architecture that boosts low-speed torque by 30%.
Hardware and software optimized for mini scale, compatible with chassis smaller than 1/16 scale.
The BEC supports selectable output voltages of 6.0V, 7.4V, and 8.4V, with a maximum output current of 3A.
Built-in multiple protection mechanisms, including ESC over-temperature protection, overload protection, low-voltage cutoff, throttle signal loss protection, and motor stall protection.
Specifications:
Gecko S1212 Pro:
Out-runner Motor Design
KV(RPM/Volt): 3500KV (est.)
MAX Watts: 120W
Lipo (S): 2S
Max Amps: 34A
Rotor Poles: 14
Shaft(mm): 2mm
Mini 24 Pro ESC Specifications:
Voltage input: 2-3S
Continuous current: 15A
Peak Current: 30A
E.C: 6V, 7.4V, 8.4V @ 3 amps
Built in switch
Programmable via Optional Program Card
Battery Connection: PH2.0- 2 Pin Female Plug
Motor Connetion:PH2.0-3 Pin Female Plug
Weight: 8.7g (including wire)
Dimension: 23.4 x 15 x 11.1mm
Package total weight: 62.00 grams (incl. packaging)
Package size: 6.00 x 9.00 x 4.00cm
Factory description: Rocket Racing Rocket-RC Mini Crawler Gecko S1212 FOC Brushless Motor & Mini 24 Pro ESC
220°C temperature-resistant insulated copper wire. 0.2mm silicon steel sheet reduces eddy current loss, enhancing magnetic flux density
Imported precision bearings and premium magnetic circuit system.
Triple core components ensure stable output under extreme conditions.
Smooth Operation & Exceptional Performance
The rotor has been calibrated with high-precision dynamic balancing, which reduces vibration, improves energy efficiency, and provides smooth low-speed control.
Small size, high torque: Powerful at low speeds and even stronger at high speeds.
ESC Features:
Designed for all-weather conditions with waterproof and dustproof protection, delivering outstanding start-up, acceleration, and linear response.
Compatible with sensorless brushless and brushed motors. Provides ultra-low-speed linear control, enabling smooth and stable start-up from as low as 0.1 km/h.
Equipped with sensorless FOC for high torque and low-speed performance, featuring a high magnetic flux MOSFET drive architecture that boosts low-speed torque by 30%.
Hardware and software optimized for mini scale, compatible with chassis smaller than 1/16 scale.
The BEC supports selectable output voltages of 6.0V, 7.4V, and 8.4V, with a maximum output current of 3A.
Built-in multiple protection mechanisms, including ESC over-temperature protection, overload protection, low-voltage cutoff, throttle signal loss protection, and motor stall protection.
Specifications:
Gecko S1212 Pro:
Out-runner Motor Design
KV(RPM/Volt): 3500KV (est.)
MAX Watts: 120W
Lipo (S): 2S
Max Amps: 34A
Rotor Poles: 14
Shaft(mm): 2mm
Mini 24 Pro ESC Specifications:
Voltage input: 2-3S
Continuous current: 15A
Peak Current: 30A
E.C: 6V, 7.4V, 8.4V @ 3 amps
Built in switch
Programmable via Optional Program Card
Battery Connection: PH2.0- 2 Pin Female Plug
Motor Connetion:PH2.0-3 Pin Female Plug
Weight: 8.7g (including wire)
Dimension: 23.4 x 15 x 11.1mm
Product weight: 62.00 grams
Package size: 6.00 x 9.00 x 4.00cm
Factory description: Rocket Racing Rocket-RC Mini Crawler Gecko S1212 FOC Brushless Motor & Mini 24 Pro ESC
Brushless Motor Breakthrough Rocket specializes in electronic products development and manufacturing. Currently, they are committed to researching and developing, and manufacturing brushless motors for RC cars scaling from 1/10th to 1/5th. No matter which level you're at, there's always a set of suitable motor that's right for you!
Rocket motor only uses high quality material to give your car the rocket-like speed. CNC machined 6061 T6 billet aluminum can, its motors are also ROAR legal. Their motor products features maximum energy conversion, and have precision balancing rotors, giving them smoothness they need for best reliability and maximum RPM.
Brushless Motor Breakthrough Rocket specializes in electronic products development and manufacturing. Currently, they are committed to researching and developing, and manufacturing brushless motors for RC cars scaling from 1/10th to 1/5th. No matter which level you're at, there's always a set of suitable motor that's right for you!
Rocket motor only uses high quality material to give your car the rocket-like speed. CNC machined 6061 T6 billet aluminum can, its motors are also ROAR legal. Their motor products features maximum energy conversion, and have precision balancing rotors, giving them smoothness they need for best reliability and maximum RPM.
